49
AVR-1803/883
C504SB 963 9003 178 Ceramic 220pF/50V
C504SL 963 9003 178 Ceramic 220pF/50V
C504SR 963 9003 178 Ceramic 220pF/50V
C505C 963 9003 181 Ceramic 33pF/500V
C505FL 963 9003 181 Ceramic 33pF/500V
C505FR 963 9003 181 Ceramic 33pF/500V
C505SB 963 9003 181 Ceramic 33pF/500V
C505SL 963 9003 181 Ceramic 33pF/500V
C505SR 963 9003 181 Ceramic 33pF/500V
C506C 963 9005 312 Electrolytic 100uF/10V
C506FL 963 9005 312 Electrolytic 100uF/10V
C506FR 963 9005 312 Electrolytic 100uF/10V
C506SB 963 9005 312 Electrolytic 100uF/10V
C506SL 963 9005 312 Electrolytic 100uF/10V
C506SR 963 9005 312 Electrolytic 100uF/10V
C507C 963 9003 194 Mylar film 0.0022uF/100V
C507FL 963 9003 194 Mylar film 0.0022uF/100V
C507FR 963 9003 194 Mylar film 0.0022uF/100V
C507SB 963 9003 194 Mylar film 0.0022uF/100V
C507SL 963 9003 194 Mylar film 0.0022uF/100V
C507SR 963 9003 194 Mylar film 0.0022uF/100V
C601 963 9005 914 Electrolytic 4.7uF/50V
C602 963 9005 914 Electrolytic 4.7uF/50V
C603 963 9005 914 Electrolytic 4.7uF/50V
C603B 963 9004 698 Ceramic chip 0.01uF/50V
C604 963 9005 914 Electrolytic 4.7uF/50V
C604B 963 9004 698 Ceramic chip 0.01uF/50V
C605 963 9006 036 Electrolytic 470uF/6.3V
C605B 963 9004 627 Ceramic chip 33pF/50V
C606 963 9005 765 Electrolytic 10uF/35V
C606B 963 9004 575 Ceramic chip 100pF/50V
C606CK 963 9004 575 Ceramic chip 100pF/50V
C607 963 9005 765 Electrolytic 10uF/35V
C607B 963 9005 765 Electrolytic 10uF/35V
C607T 963 9004 575 Ceramic chip 100pF/50V
C608 963 9006 036 Electrolytic 470uF/6.3V
C608ST 963 9004 575 Ceramic chip 100pF/50V
C609 963 9006 036 Electrolytic 470uF/6.3V
C610 963 9005 765 Electrolytic 10uF/35V
C610BL 963 9005 765 Electrolytic 10uF/35V
C611B 963 9005 875 Electrolytic 47uF/25V
C612 963 9005 794 Electrolytic 100uF/16V
C612B 963 9005 875 Electrolytic 47uF/25V
C613B 963 9004 698 Ceramic chip 0.01uF/50V
C614 963 9004 753 Ceramic chip 0.047uF/50V
C614B 963 9004 698 Ceramic chip 0.01uF/50V
C615B 963 9005 914 Electrolytic 4.7uF/50V
C617BL 963 9004 630 Ceramic chip 39pF/50V
C618BL 963 9004 698 Ceramic chip 0.01uF/50V
C618BR 963 9004 698 Ceramic chip 0.01uF/50V
C681 963 9004 520 Ceramic 100pF/50V
Ref. No. Part No. Part Name RemarksRef. No. Part No. Part Name Remarks
R737L 963 9004 193 Carbon chip 22 ohm 1/16W
R737R 963 9004 193 Carbon chip 22 ohm 1/16W
R751L 963 9006 065 Carbon chip 200 kohm 1/16W
R751R 963 9006 065 Carbon chip 200 kohm 1/16W
VR106 963 0105 208 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C101SB 963 9005 312 Electrolytic 100uF/10V
C102SB 963 9005 778 Electrolytic 10uF/50V
C103SB 963 9003 084 Ceramic 100pF/500V
C104SB 963 9003 084 Ceramic 100pF/500V
C105SB 960 9003 108 Ceramic 0.022uF/25V
C107SB 963 9003 097 Mylar film 0.1uF/250V
C201ML 963 9004 575 Ceramic chip 100pF/50V for E3,EU
C201MR 963 9004 575 Ceramic chip 100pF/50V for E3,EU
C202ML 963 9005 914 Electrolytic 4.7uF/50V for E3,EU
C202MR 963 9005 914 Electrolytic 4.7uF/50V for E3,EU
C203ML 963 9005 914 Electrolytic 4.7uF/50V for E3,EU
C203MR 963 9005 914 Electrolytic 4.7uF/50V for E3,EU
C251 963 9004 698 Ceramic chip 0.01uF/50V
C252 963 9004 698 Ceramic chip 0.01uF/50V
C253 963 9004 698 Ceramic chip 0.01uF/50V
C457 963 9004 575 Ceramic chip 100pF/50V
C458 963 9004 575 Ceramic chip 100pF/50V
C459 963 9004 575 Ceramic chip 100pF/50V
C460 963 9004 575 Ceramic chip 100pF/50V
C501C 963 9005 820 Electrolytic 22uF/16V
C501FL 963 9005 820 Electrolytic 22uF/16V
C501FR 963 9005 820 Electrolytic 22uF/16V
C501M 963 9005 765 Electrolytic 10uF/35V
C501SB 963 9005 820 Electrolytic 22uF/16V
C501SL 963 9005 820 Electrolytic 22uF/16V
C501SR 963 9005 820 Electrolytic 22uF/16V
C502C 963 9005 765 Electrolytic 10uF/35V
C502FL 963 9005 765 Electrolytic 10uF/35V
C502FR 963 9005 765 Electrolytic 10uF/35V
C502SB 963 9005 765 Electrolytic 10uF/35V
C502SL 963 9005 765 Electrolytic 10uF/35V
C502SR 963 9005 765 Electrolytic 10uF/35V
C503C 963 9003 165 Ceramic 220pF/500V
C503FL 963 9003 165 Ceramic 220pF/500V
C503FR 963 9003 165 Ceramic 220pF/500V
C503SB 963 9003 165 Ceramic 220pF/500V
C503SL 963 9003 165 Ceramic 220pF/500V
C503SR 963 9003 165 Ceramic 220pF/500V
C504C 963 9003 178 Ceramic 220pF/50V
C504FL 963 9003 178 Ceramic 220pF/50V
C504FR 963 9003 178 Ceramic 220pF/50V
