Denon AVR-988 Specification Sheet

Partner: Denon
Model: AVR-23/28/38/43/5805CI +
888 + 988
Device Type: AV Surround Receiver
Main_Mute_On/Off_Fb D High to indicate the current main volume mute state.
Zone_2_On/Off_Fb D High to indicate the current zone 2 status.
Zone_2_Input_*_Fb D High to indicate the current zone 2 source.
Zone_2_Volume_Bar
A
Analog value indicating the current zone 2 volume level. To be displayed using
a bar graph on a touch panel.
Zone_2_Volume_Text$ S Serial signal indicating the current zone 2 volume level.
Zone_2_Mute_On/Off_Fb D High to indicate the current zone 2 volume mute state.
Zone_3_On/Off_Fb D High to indicate the current zone 3 status.
Zone_3_Input_*_Fb D High to indicate the current zone 3 source.
Zone_3_Volume_Bar
A
Analog value indicating the current zone 3 volume level. To be displayed using
a bar graph on a touch panel.
Zone_3_Volume_Text$ S Serial signal indicating the current zone 3 volume level.
Zone_3_Mute_On/Off_Fb D High to indicate the current zone 3 volume mute state.
Zone_4_On/Off_Fb D High to indicate the current zone 4 status.
Zone_4_Input_*_Fb D High to indicate the current zone 4 source.
<Surround_Mode>_Fb D High to indicate the currently active surround mode.
<Channel>_Text$ S Serial signal indicating the current level for the channel
Auto/PCM/DTS/ANALOG/External_In_ Fb D High to indicate the currently selected digital input.
Video_Input_*_Fb D High to indicate the currently selected video input.
Tone_Defeat_On/Off_Fb D High to indicate the current tone defeat status.
Cinema_EQ_On/Off_Fb D High to indicate the current state of the cinema EQ.
Record_* _Input_Fb D High to indicate the current record input.
*_Band_*_Fb
D
High to indicate the current tuner band (currently Analog, HD, XM and DAB
(Europe).
