Denon AVR-S540BT User Manual

.
MASTER VOLUME
Q
9
Q
6
Q
7
Q
8
W
0
Q
5
Q
4
N
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the SUBWOOFER
connectors.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
O
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v p. 86)
P
QUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 65)
Q
TONE CONTROL ON/OFF button
Set the tone control function to on/off. (v
p. 54)
R
BASS/TREBLE button
Selects the range for which to adjust the tone. (v p. 54)
S
USB port (T)
This is used to connect USB storages (such as USB memory devices)
and the USB cable supplied. (v
p. 33)
T
Tone adjustment buttons (ADJUST 0 1)
Adjusts the tonal quality of the sound. (v
p. 54)
0
BASS/TREBLE button and ADJUST 0 1 buttons can be operated when the
“Tone” setting is “On”. (v p. 54)
Contents Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

Denon AVR-S540BT Specifications

General

Channels	5.2
Power Output per Channel	70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
HDMI Inputs	5
HDMI Outputs	1
HDMI Version	2.0a
HDCP Support	2.2
4K/60 Hz Pass-through	Yes
Dolby Format	Dolby TrueHD, Dolby Digital Plus
DTS Format	DTS-HD Master Audio
Auto Speaker Setup	Yes (Audyssey MultEQ)
Bluetooth	Yes
FM Tuner	Yes
AM Tuner	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
Dimensions (W x H x D)	434 x 151 x 319 mm
Ethernet Port	No
Wi-Fi	No
HDR Support	HDR10, HLG
Frequency Response	10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio	98 dB (IHF-A weighted)
USB Port	Yes (Front)
