Page #21 background imageLoading...
Page #21 background image
0
Use the illustration below as a guide for how high each speaker should be
installed. The height does not need to be exactly the same.
.
GViewed from the sideH
Surround
speaker
Front speaker
o
When 5.1-channel speakers are installed
.
z1
z2
FL
SW
C
SL
FR
SR
z
1 22° - 30°
z
2 120°
Contents
Connections Playback Settings Tips Appendix
21
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-S540BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-S540BT and is the answer not in the manual?

Denon AVR-S540BT Specifications

General IconGeneral
Channels5.2
Power Output per Channel70 W (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)140 W
HDMI Inputs5
HDMI Outputs1
HDMI Version2.0a
HDCP Support2.2
4K/60 Hz Pass-throughYes
Dolby FormatDolby TrueHD, Dolby Digital Plus
DTS FormatDTS-HD Master Audio
Auto Speaker SetupYes (Audyssey MultEQ)
BluetoothYes
FM TunerYes
AM TunerYes
Input Sensitivity/Impedance200 mV / 47 kOhm
Dimensions (W x H x D)434 x 151 x 319 mm
Ethernet PortNo
Wi-FiNo
HDR SupportHDR10, HLG
Frequency Response10 Hz - 100 kHz - +1/-3 dB
Total Harmonic Distortion0.08% (20 Hz - 20 kHz)
Signal-to-Noise Ratio98 dB (IHF-A weighted)
USB PortYes (Front)
