Denon AVR-S660H User Manual

Sound mode that can be selected for each input signal
0
The following sound modes can be selected using the MOVIE, MUSIC and GAME buttons.
0
Adjust the sound field effect with the menu “Surr.Parameter” to enjoy surround sound the way you like it. (v p. 122)
.
Stereo
SSS
Dolby PLg Movie z2 S
Dolby PLg Music z2 S
Dolby PLg Game z2 S
DTS Neo:6 Cinema z2 S
DTS Neo:6 Music z2 S
Multi Ch Stereo
SSS
Mono Movie
S
Rock Arena
S
Jazz Club
S
Matrix
S
Video Game
S
Virtual
SSS
2-channel z1
GAME button
MUSIC button
MOVIE buttonSound mode
Input signal
z1
2-channel also includes analog input.
z2
This mode plays back 2-channel sources in 5.1-channel playback. It cannot be selected when headphones are used or when the speaker configuration is front speakers
only.
Contents Connections Playback Settings Tips Appendix
103
Front panel Display Rear panel Remote Index

Denon AVR-S660H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	6
Line-in	Yes
Composite video in	2
USB ports quantity	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Optical drive included	No
3D	-
Display	VFL
HDCP version	2.3
Product color	Black
Audio decoders	DTS Neo:6, DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	340 W
Package depth	435 mm
Package width	523 mm
Package height	232 mm
Package weight	9700 g

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	7800 g
