Calling up the settings
1
Press QUICK SELECT.
The Quick Select settings registered to the button you pressed are
called up.
0
The default settings for the input source are as shown below.
Button Input source
QUICK SELECT 1 CBL/SAT
QUICK SELECT 2 Blu-ray
QUICK SELECT 3 Game
QUICK SELECT 4 HEOS Music
0
Volume is not registered to Quick Select Plus in the factory default settings.
See “Changing the settings” to register volume to Quick Select Plus. (v p. 111)
Contents Connections Playback Settings Tips Appendix
110
Front panel Display Rear panel Remote Index

Denon AVR-S660H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	6
Line-in	Yes
Composite video in	2
USB ports quantity	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Optical drive included	No
3D	-
Display	VFL
HDCP version	2.3
Product color	Black
Audio decoders	DTS Neo:6, DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	340 W
Package depth	435 mm
Package width	523 mm
Package height	232 mm
Package weight	9700 g

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	7800 g
