o
Speaker Select
Select whether to adjust tones for individual speakers or for all
speakers.
All: Adjust all speaker tones together.
Left/Right
(Default) :
Adjust the left and right speaker tones
together.
Each: Adjust the tone for each speaker.
o
Adjust EQ
Adjust tonal balance for each frequency band.
1. Select the speaker.
2. Select the adjustment frequency band.
63 Hz / 125 Hz / 250 Hz / 500 Hz / 1 kHz / 2 kHz / 4 kHz / 8 kHz /
16 kHz
3. Adjust the level.
–20.0 dB – +6.0 dB (Default : 0.0 dB)
Contents
Connections Playback Settings Tips Appendix
132
Front panel Display Rear panel Remote Index

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-S660H and is the answer not in the manual?

Denon AVR-S660H Specifications

General IconGeneral
Receiver typestereo
Frequency range10 - 100000 Hz
Input sensitivity200 mV
Audio output channels5.2 channels
Signal-to-Noise Ratio (SNR)98 dB
Total Harmonic Distortion (THD)1 %
Power output per channel (1KHz@6 Ohm)135 W
Power output per channel (20-20KHz@8 Ohm)75 W
HDMI in6
Line-inYes
Composite video in2
USB ports quantity1
Connectivity technologyWired & Wireless
Speakers connectivity typeRCA
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Optical drive includedNo
3D-
DisplayVFL
HDCP version2.3
Product colorBlack
Audio decodersDTS Neo:6, DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Volume controlRotary
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)340 W
Package depth435 mm
Package width523 mm
Package height232 mm
Package weight9700 g
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height151 mm
Weight7800 g
