Denon AVR-S660H User Manual

On Screen Disp.
Select the on-screen display user interface preferences.
o
Volume
Sets where to display the volume level.
Bottom
(Default):
Display at the bottom.
Top: Display at the top.
Off: Turn display off.
0
When the master volume display is hard to see when superimposed text
(closed captioning) or movie subtitles are present, set to “Top”.
o
Info
Displays status of operation temporarily when the input source is
switched.
On
(Default):
Turn display on.
Off: Turn display off.
o
Now Playing
Sets the display time for the playback display when the input source is
“HEOS Music” or “Tuner”.
Always On
(Default) :
Show display continuously.
Auto Off:
Show display for 30 seconds after
operation.
Contents Connections Playback Settings Tips Appendix
139
Front panel Display Rear panel Remote Index

Denon AVR-S660H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	6
Line-in	Yes
Composite video in	2
USB ports quantity	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Optical drive included	No
3D	-
Display	VFL
HDCP version	2.3
Product color	Black
Audio decoders	DTS Neo:6, DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	340 W
Package depth	435 mm
Package width	523 mm
Package height	232 mm
Package weight	9700 g

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	7800 g
