Denon AVR-S660H User Manual

Connecting to a home network (LAN)
This unit can connect to a network using a wired LAN or wireless LAN.
You can connect this unit to your home network (LAN) to enable various
types of playback and operations as described below.
0
Playback of network audio such as Internet Radio and from your media
server(s)
0
Playback of streaming music services
0
Using the Apple AirPlay function
0
Operation on this unit via the network
0
Operation with the HEOS wireless multi-room sound system
0
Firmware Update
For connections to the Internet, contact an ISP (Internet Service
Provider) or a computer shop.
Wired LAN
To make connections via wired LAN, use a LAN cable to connect the
router to this unit as shown in the figure below.
.
Internet
Modem
PC
NAS
(Network Attached Storage)
Router
To WAN side
To LAN port
To LAN port
LAN port / Ethernet
connector
LAN port / Ethernet
connector
Contents
Connections Playback Settings Tips Appendix
46
Front panel Display Rear panel Remote Index

Denon AVR-S660H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	6
Line-in	Yes
Composite video in	2
USB ports quantity	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Optical drive included	No
3D	-
Display	VFL
HDCP version	2.3
Product color	Black
Audio decoders	DTS Neo:6, DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	340 W
Package depth	435 mm
Package width	523 mm
Package height	232 mm
Package weight	9700 g

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	7800 g
