Denon AVR-S660H User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
.
2
Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3
Put the rear cover back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
Approx. 23 ft/7 m
30° 30°
Contents
Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Denon AVR-S660H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	6
Line-in	Yes
Composite video in	2
USB ports quantity	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Optical drive included	No
3D	-
Display	VFL
HDCP version	2.3
Product color	Black
Audio decoders	DTS Neo:6, DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Volume control	Rotary
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	340 W
Package depth	435 mm
Package width	523 mm
Package height	232 mm
Package weight	9700 g

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	7800 g
