Page #124 background imageLoading...
Page #124 background image
4. Protection Pass Mode 5. Network Initialization Mode
4.1. Actions
This mode allows the power to be turned on without activating protections.
This mode functions in the same way as normal power-on, except that protections are not activated.
When using the protection pass mode, do not connect speakers to the speaker terminals.
4.2. Operations
AVR-X1500H
While holding down buttons "
TUNER PRESET CH +
", "
ZONE2 SOURCE
" and "
STATUS
"
simultaneously, press the power button to turn on the power.
AVR-S740H
While holding down buttons "
ZONE2 SOURCE
", "
TUNER PRESET CH +
" and "
TUNE +
"
simultaneously, press the power button to turn on the power.
The device returns to the normal display message after the following is displayed.
Protection Pass
This is displayed for 5 seconds before returning to the normal display.
5.1. Actions
The following items are initialized.
(1) Network setup
(2) Friendly Name
(3) Auto Update setting
(4) Allow Update setting
(5) Time Zone setting
(6) Queue list
(7) Internet Radio recently played station
(8) Quick Select playback station
(9) AirPlay Password
(10) Bluetooth Pairing History
5.2. Operations
AVR-X1500H
When the power is on and the input source is HEOS Music, press and hold the "
TUNERPRESET CH
+
" and "
ZONE2 ON/OFF
" buttons for more than 3 seconds.
AVR-S740H
When the power is on and the input source is HEOS Music, press and hold the "
ZONE2 SOURCE
" and
"
ZONE2 ON/OFF
" buttons for more than 3 seconds.
Initializing Display
Network Reset...
Complete Display
Completed
This is displayed for 5 seconds before returning to the normal display.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
124
