Denon AVR-S740H Service Manual

1.6. Conrmation items for the video system
See the block diagram g.VXXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.V01
V01:VIDEO PASS
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : On
・ CVBS input ⇒ CVBS output
(
b
The input source can be switched to any source except CBL/SAT.)
2 HDMI pass g.V02
V03:HDMI PASS
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : Off
・ HDMI input (except 4K) ⇒ HDMI output (except 4K)
・ HDMI input (4K) ⇒ HDMI output (4K) & Vol display
(
b
The input source can be switched to any source except CBL/SAT.)
3 HDMI CEC g.V03
V04:HDMI CEC
Input Source : CBL/SAT
HDMI Control : On
MAIN ZONE : On
ZONE2 : Off
・ When the power supply of a TV is put in the standby mode, make sure that the power supply
of this unit is also put in the standby mode.
(
b
The input source can be switched to any source except CBL/SAT.)
・ The ARC path can also be checked (check this using the TV input source).
4
HDMI Audio
(Audio : AVR)
g.A04a
g.A04b
V05:H.AUDIO-AVR
Input Source : CBL/SAT
HDMI Control : Off
HDMI Audio : AVR (if checking the audio output from
AVR)
・ HDMI input (PCM, DolbyDigital, DTS) ⇒ Speaker output.
・ HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
5
HDMI Audio
(Audio : TV)
g.V05
V06:H.AUDIO-TV
HDMI Audio : TV (if checking the audio output from TV)・ HDMI input (PCM, DolbyDigital, DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
6 GUI g.V06
V07:GUI MENU ON
Input Source : CBL/SAT
Setup Menu : On
MAIN ZONE : On
ZONE2 : Off
・GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
128

Denon AVR-S740H Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 0.08% THD)
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
Bluetooth	Yes
Wi-Fi	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
Power Output per Channel (6 Ohms)	110 W (6 Ohms, 1 kHz, 0.7% THD)
4K/Ultra HD Upscaling	Yes
Phono Input	Yes
Dolby Support	Dolby Atmos, Dolby TrueHD, Dolby Surround
Auto Calibration	Audyssey MultEQ
Input Sensitivity/Impedance	200 mV / 47 kOhms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet	Yes
USB Port	Yes (front)
AM/FM Tuner	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
HDR Support	HDR10, HLG, Dolby Vision
Wireless Audio	AirPlay 2
DTS Support	DTS:X, DTS-HD Master Audio
Zone Audio	Zone 2
Frequency Response	10 Hz - 100 kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.08% (20 Hz - 20 kHz)
Built-in DAC	192 kHz / 24-bit
