Denon AVR-S750H Service Manual

1.6. Conrmation items for the video system
See the block diagram g.VXXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.V01
V01:VIDEO PASS
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : On
• CVBS input ⇒ CVBS output
(
b
The input source can be switched to any source except CBL/SAT.)
2 HDMI pass g.V02
V03:HDMI PASS
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : Off
• HDMI input (except 4K) ⇒ HDMI output (except 4K)
• HDMI input (4K) ⇒ HDMI output (4K) & Vol display
(
b
The input source can be switched to any source except CBL/SAT.)
3 HDMI CEC g.V03
V04:HDMI CEC
Input Source : CBL/SAT
HDMI Control : On
MAIN ZONE : On
ZONE2 : Off
• When the power supply of a TV is put in the standby mode, make sure that the power supply
of this unit is also put in the standby mode.
(
b
The input source can be switched to any source except CBL/SAT.)
• The ARC path can also be checked (check this using the TV input source).
4
HDMI Audio
(Audio : AVR)
g.A04a
g.A04b
V05:H.AUDIO-AVR
Input Source : CBL/SAT
HDMI Control : Off
HDMI Audio : AVR (if checking the audio output from
AVR)
• HDMI input (PCM, DolbyDigital, DTS) ⇒ Speaker output.
• HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
5
HDMI Audio
(Audio : TV)
g.V05
V06:H.AUDIO-TV
HDMI Audio : TV (if checking the audio output from TV) • HDMI input (PCM, DolbyDigital, DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
6 GUI g.V06
V07:GUI MENU ON
Input Source : CBL/SAT
Setup Menu : On
MAIN ZONE : On
ZONE2 : Off
• GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
131

Denon AVR-S750H Specifications

General

Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	10 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	75 W
AirPlay	Yes
Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby TrueHD
Volume control	Rotary
HDMI in	6
Composite video in	2
Digital audio optical in	1
Package depth	432 mm
Package width	523 mm
Package height	229 mm
Package weight	10614 g
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	400 W
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Image formats supported	JPEG
Speakers connectivity type	RCA

Weight and Dimensions

Depth	330 mm
Height	152 mm
Weight	8618 g
