Denon is a trademark or registered trademark of D&M Holdings, Inc.
* All specs can be subject to change
* Available only in Black
KEY FEATURES
• 7.2ch platform
• 185W (6ohm, 1kHz, 1ch driven)
• HDMI – 8 inputs / 2 outputs
• 4K/60Hz full-rate pass-through
• Built-in Wifi and Bluetooth
• Networking: AirPlay, Android push playback, Internet Radio,
Pandora, Spotify Connect,Sirius XM, DSD play back, DLNA 1.5
• Audyssey MultEQ setup with measuring microphone included
in the box / Dynamic EQ & Volume
STATE-OF-THE-ART DENON SOLUTIONS FOR MAXIMISING
CONTENT QUALITY AND CONNECTIVITY
• HDMI : Front 1in , Rear 7in/2 dual out
• Digital audio inputs : 2 Opt /1 Coax
• Audio: 4in, Video: Composite 2in, Component, 2in/1out
• Front panel USB input with iPod digital direct
• AM/FM Radio
• 2-zone/2-source via amplified zone
EASE-OF-USE AND OTHER FEATURES
• ECO mode
• Setup assistant with icon-based GUI
• 4 Quick Select buttons and RC buttons - can be used to store
favorite sources, internet radio stations and preferred settings
• Horizontal layout speaker terminals with color labelling
• Speaker cable labels supplied
• Larger Character Display
• Sleep Timer, set up to 120 minutes in 10-minute increments
• Standby HDMI pass-through
• Simple Remote handset
• Android, Kindle Fire and iOS remote apps available
|V01|
Technical information
Number of power amps 7 Preamplifier section
Input sensitivity/impedance 200 mV / 47 kohms
Power output 185 watts per channel Frequency response 10 Hz - 100 kHz — +1, –3 dB
(6 ohms, 1kHz, 1ch driven) (DIRECT mode)
S/N Ratio 100 dB (IHF-A weighted, DIRECT mode)
90 watts per channel
(8 ohms, 20Hz - 20 kHz, THD 0.08%, 2ch driven) FM section
Tuning frequency range 87.5 - 107.9 MHz
Output connectors 4 - 16 ohms
AM section
Tuning frequency range 520 - 1710 kHz
General
Power supply AC 120 V, 60 Hz
Power consumption 460 W (Standby 0.1 W, CEC standby 0.5 W)
Dimensions (W x H x D) 17.1” x 6.6”x 13.3”
Weight 21.4 lbs
Ports
IN HDMI (Front 1) x 7
Component x 2
Composite (video) x 2
Analogue Audio x 4
Digital Optical x 2
Digital Coaxial x 1
OUT HDMI Monitor x 2
Audio Preout (SW) 0.2 ch
Component Monitor x 1
Phones x 1
OTHER Ethernet x 1
USB Port x 1
Microphone Port x 1
FM Tuner Antenna x 1
AM Tuner Antenna x 1
Built-in Bluetooth, Wi-Fi, AirPlay and DLNA
Stream your favorite tracks wirelessly to the AVR-S900W directly
from your Bluetooth-enabled portable devices, such as a smart-
phone, portable media player and tablet. The AVR-S900W can
recognize and remember up to 8 Bluetooth portable devices, so
your family and friends can enjoy their favorite tracks.
With the built-in Wi-Fi feature, you can connect the AVR-S900W
to your home network wirelessly and open up a whole new world
of content streaming functions, including the ability to stream
content from subscription services such as Pandora, Spotify and
SiriusXM, and listen to thousands of internet radio stations.
With AirPlay, you can wirelessly stream your favorite audio tracks
directly from your iOS device, including the iPod, iPod touch and
iPad. DLNA 1.5 certification lets you enjoy streaming content via
your PC, Mac or Android device.
Via our Denon Remote App, you can wirelessly control the AVR-
S900W from your favorite portable device. The Denon Remote
App is available in iOS and Android versions, and is also available
for the Kindle Fire.
8 HDMI Inputs, Dual HDMI Outputs
Equipped with no less than 8 HDMI inputs, the AVR-S900W fea-
tures 7 HDMI inputs on the rear panel, along with another HDMI
input on the front panel that lets you conveniently connect your
favorite game console, HDTV camcorder or other HDMI device.
The dual HDMI outputs let you drive two separate HDMI-equipped
displays at the same time.
Powerful 7 Channel Discrete Amplifier with Eco Mode
With each channel rated at a maximum power of 185 watts, the
AVR-S900W features a power amplifier design that incorporates
multiple high current discrete output devices, with identical cir-
cuit topology on all 7 channels.
Our new Eco Mode provides the ability to reduce overall power
consumption and features an on-screen Eco Meter that lets you
see the power consumption reduction effect.
The Auto Eco mode automatically switches between normal and
Eco modes, depending on the volume level chosen, and the power
amplifier block is rated to drive low impedance speaker loads,
down to 4 ohms, for compatibility and stability with virtually any
loudspeaker model.
Audyssey bronze Built-in
The AVR-S900W features the Audyssey bronze family of DSP
technologies, which includes MultEQ room acoustic measure-
ment and correction. Via the supplied measuring microphone, the
MultEQ system first measures actual in-room response from all
the speakers, including the subwoofer, and then quickly gener-
ates multiple precision digital filters that ensure the smoothest
possible response.
Audyssey Dynamic Volume uses DSP algorithms to smooth out
jumps in volume, such as commercials, letting you hear clearly
even at lower listening levels. Audyssey Dynamic EQ provides
sophisticated tonal balancing, delivering smooth, rich response
across the entire audio range.
Multi-Room Listening
Thanks to the AVR-S900W’s flexible Amp Assign function, you
can choose to power a 5.1 channel home theater surround
system, and dedicate the 2 additional amp channels to deliver
stereo sound to a pair of speakers in another room. Watch a sur-
round sound movie in the main room with the ability to have a
separate stereo source playing in a second room.
Dual Subwoofer Outputs
Depending on the location of the subwoofer in a listening room
relative to the listening position, the deep bass quality can be
marred by in-room resonances that negatively affect bass qual-
ity, with peaks and dips that together produce boomy bass and
muddy bass detail.
Equipped with dual subwoofer outputs, the AVR-S900W lets you
use two subwoofers, placed in different locations in the listening
room. By having two subs in different locations in the room, the
bass quality can very often be significantly better due to re-
sponse averaging, with smoother, deeper bass free of annoying
peaks and dips.
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey
07430 USA
TEL: 201-762-6500
usa.denon.com
