F
HDMI connectors
Used to connect devices equipped with HDMI connectors.
0
“Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel)” (v
p. 48)
0
“Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)” (v p. 49)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v
p. 52)
0
“Connecting a DVD player or Blu-ray Disc player” (v p. 53)
G
Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
0
“Connection 3 : TV equipped without an HDMI
connector” (v p. 50)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 52)
H
AC inlet (AC IN)
Used to connect the power cord. (v
p. 62)
I
FM/AM antenna terminals (ANTENNA)
Used to connect FM antennas and AM loop antennas. (v p. 57)
J
Speaker terminals (SPEAKERS)
Used to connect speakers. (v
p. 32)
K
REMOTE CONTROL jack
Used to connect infrared receivers/transmitters in order to operate this
unit and external devices from a different room. (v
p. 61)
NOTE
0
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
Contents Connections Playback Settings Tips Appendix
20
