Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 189)
Perform “Speaker Layout” settings to suit the number of rooms and speaker configuration to be installed. (v p. 189)
Playback speaker in each zone
“Amp Assign” settings
“Speaker Layout” settings
MAIN ZONE ZONE2 Height Surround Back
5.1-channel playback 2-channel (Pre-out)
Can be set in all “Amp
Assign” settings.
No No
7.1-channel (surround back) 2-channel (Pre-out) 7.1ch No 2 spkrs
7.1-channel (front height) 2-channel (Pre-out) 7.1ch Front Height No
7.1-channel (top front) 2-channel (Pre-out) 7.1ch Top Front No
7.1-channel (top middle) 2-channel (Pre-out) 7.1ch Top Middle No
7.1-channel (front Dolby Atmos Enabled
speaker)
2-channel (Pre-out) 7.1ch Front Dolby No
7.1-channel (surround Dolby Atmos Enabled
speaker)
2-channel (Pre-out) 7.1ch Surround Dolby No
5.1-channel (bi-amp connection for front
speaker)
2-channel (Pre-out) 5.1ch (Bi-Amp) No No
5.1-channel + second pair of front speaker 2-channel (Pre-out) 5.1ch + Front B No No
5.1-channel
2-channel
(Speaker out)
5.1ch + ZONE2
(Default)
No No
0
The sound mode that can be selected varies according to the speaker configuration.
