Connecting 5.1-channel speakers: Bi-amp connection of front speakers
This system plays back 5.1-channels. You can use the bi-amp connection for front speakers. Bi-amp connection is a method to connect separate
amplifiers to the tweeter terminal and woofer terminal of a speaker that supports bi-amplification. This connection enables back EMF (power returned
without being output) from the woofer to flow into the tweeter without affecting the sound quality, producing a higher sound quality.
FL FR
SW C
SL
SR
(Bi-Amp) (Bi-Amp)
0
Set “Amp Assign” to “5.1ch (Bi-Amp)” in the menu. (v p. 189)
NOTE
0
When making bi-amp connections, be sure to remove the short-circuiting plate or
wire between the speaker’s woofer and tweeter terminals.
wqwq
(R) (L)
FLFR
SW
CSRSL
Contents Connections Playback Settings Tips Appendix
47
Front panel Display Rear panel Remote Index

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X1800H and is the answer not in the manual?

Denon AVR-X1800H Specifications

General IconGeneral
Amplifier Channels7.2
HDMI Version2.1
HDCP Support2.3
eARCYes
Dolby AtmosYes
DTS:XYes
Dolby SurroundYes
DTS Neural:XYes
BluetoothYes
AirPlay 2Yes
HEOS Multi-RoomYes
Input Sensitivity/Impedance200 mV / 47 kohms
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output per Channel80W (8 ohms, 20Hz - 20kHz, 0.08% THD)
HDMI Inputs6
HDR SupportHDR10+, Dolby Vision, HLG
Wi-FiYes
Phono InputYes
Frequency Response10Hz - 100kHz
Total Harmonic Distortion0.08%
Signal-to-Noise Ratio98dB
