o
Example layout when using surround Dolby
Atmos Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel
system but with surround Dolby Atmos Enabled speakers.
C
FL FR
SW
SL SR
SDL SDR
0
Set “Amp Assign” to “7.1ch” and set “Height” to “Surround Dolby” in the menu.
(v p. 189, 191)
SDR SDL
SW
FLFR C SR SL
Contents Connections Playback Settings Tips Appendix
46
Front panel Display Rear panel Remote Index
