Denon AVR-X2500H Service Manual

Paths to be conrmed Display Settings What to conrm
4 HDMI
g.A04a
g.A04b
A05:HDMI
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : Surround Back
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN ZONE)
g.A05a
g.A05b
A06:AD
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Vol 60(-20dB)
Amp assign : Surround Back
Speaker Cong ALL Speaker = Small / SW = Yes
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Pre OUT output SW(20Hz)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
6
Analog Amp Assign
(Amp Assign :
ZONE2)
g.A06
A07:ASSIGN-Z2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Vol 60(-20dB)
Amp assign : ZONE2
MAIN ZONE : On
ZONE2 : On
・ Analog input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R) (Except S940)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
141

Denon AVR-X2500H Specifications

General

HDMI in	8
Composite video in	2
Ethernet LAN (RJ-45) ports	1
AirPlay	No
Display	-
Sample rate	196 kHz
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
RS-232 interface	Yes
Connectivity technology	Wired & Wireless
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions	3840 x 2160

Weight and Dimensions

Depth	340.3 mm
Width	434.3 mm
Height	167.6 mm
Weight	9389 g
