Denon AVR-X2500H Service Manual

Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
134 PE1/TXD12 THERMAL_E I SW3VPu I L I Protection detect signal input pin (for Heat sink)
135 PE0/SCK12
NET3.3V_
POWER
O L L L Ethernet power supply control(Net3.3V)
136 P64 D5V_POWER O L L H
Digital 5V power supply control pin(3.3V and 1.8V gener-
ate from 5V)(When CEC standby mode3,set to Low)
137 P63 CEC_POWER O L L H
CEC standby power supply
control(CEC5V,CEC3.3V,CEC1.8V)(When CEC standby
mode3,set to Low)
138 P62 DV_POWER1 O L L L Digital video power supply (DV5V,DV3.3V) control pin
139 P61 DV_POWER2 O L L L Digital video power supply (DV1.8V) control pin
140 VSS VSS - - - - Ground pin
141 P60 DIR_DIN O L L L DIR (PCM9211) control pin
142 VCC VCC - - - - Power supply pin
143 PD7/IRQ7/AN107 DIR_CE O L L L DIR (PCM9211) control pin
144 PG1 DIR_DOUT I DA3.3Pu I I I DIR (PCM9211) control pin
145 PD6/IRQ6/AN106 DIR_CLK O L L L DIR (PCM9211) control pin
146 PG0 DIR_RST O L L L DIR (PCM9211) control pin
147 PD5/IRQ5/AN113 788_2_HAINT I CEC3VPu Z - HDMI Rx (MN864788) audio interrupt signal det
148 PD4/IRQ4/AN112 SW_SDA I_O DV3VPu O/L O/L L HDMI TMDS switch I2C ccontrol pin for TMDS261B
149 P97
DE_RST (NR1609/
SR5013)/NC
(S940/X2500H)
O Pd Z L Video decoder (ADV7180) reset control pin
150 PD3/IRQ3/AN111 788_1_HINT I CEC3VPu Z - HDMI Tx (MN864788) interrupt signal input pin
151 VSS VSS - - - - Ground pin
152 P96 788_1_RST O Pd Z H
HDMI Tx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
153 VCC VCC - - - - Power supply pin
154 PD2/IRQ2/AN110 788_2_HINT I CEC3VPu Z - HDMI Rx (MN864788) interrupt signal input pin
155 P95 788_2_RST O Pd Z H
HDMI Rx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
156 PD1/IRQ1/AN109 788_3_HINT I CEC3VPu Z - HDMI Rx (MN864788) interrupt signal input pin
157 P94 788_3_RST O Pd Z H
HDMI Rx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
158 PD0/IRQ0/AN108
A_TO_H/
NET (NR1609/
SR5013)/ NC
(S940/X2500H)
O L L L Video PLD control pin (Net GUI:High,A to H:Low)
159 P93/AN117 THERMAL_A I SW3VPu I L I Protection detect signal input pin (for power TR)
160 P92/RXD7/AN116 THERMAL_B I SW3VPu I L I Protection detect signal input pin (for power TR)
161 P91/AN115 SW_SCL I_O DV3VPu O/L O/L L HDMI TMDS switch I2C control pin for TMDS261B
162 VSS VSS - - - - Ground pin
163 P90/TXD7/AN114
TEMP_SEN-
SOR
I I L I Temperature sensor input pin (for SRM)
164 VCC VCC - - - - Power supply pin
165
P47/IRQ15-DS/
AN007
788_3_HAINT I CEC3VPu Z - HDMI Rx (MN864788) audio interrupt signal det
166
P46/IRQ14-DS/
AN006
CURRENT_DET I/O Pd I/L L/L I/L Current level monitor pin (A/D converter)
167
P45/IRQ13-DS/
AN005
AMPSIGDET I Pd I L I Signal level monitor pin (AD converter)
168
P44/IRQ12-DS/
AN004
MODE I I I I Region setting pin
169
P43/IRQ11-DS/
AN003
KEY3 I M3VPu I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
170
P42/IRQ10-DS/
AN002
KEY2 I M3VPu I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
171
P41/IRQ9-DS/
AN001
KEY1 I M3VPu I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
172 VREFL0 VREFL0 - - - - Ground pin
173 P40 ADC_RST O I L I A/D convertor(AK5358) reset control pin
174 VREFH0 VREFH0 - - - - Power supply pin
175 AVCC0 AVCC0 - - - - Power supply pin
Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
176 P07/IRQ15
COMP_DET
(NR1609/
SR5013)/NC
(S940/X2500H)
I M3VPu I I I Component video signal detect pin
