Denon AVR-X2500H Service Manual

RCKSK0410850 0 1 0 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select Auto
RCKSK0410851 1 1 0 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select Movie
RCKSK0410852 0 0 1 0 1 0 1 0 1 1 * * * * * * * * * * Video Mode Select Game
RCKSK0410853
1
0 1 0 1 0 1 0 1 1
* * * * * * * * * *
Video Mode Select Bypass
RCKSK0410857 1 0 0 1 1 0 1 0 1 1 * * * * * * * * * * Loudness Management ON/OFF
RCKSK0410872 0 0 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(toggle)
RCKSK0410873 1 0 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(OFF)
RCKSK0410874 0 1 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(ON)
RCKSK0410875 1 1 0 1 0 1 1 0 1 1 * * * * * * * * * * ECO MODE(AUTO)
RCKSK0410945
1
0 0 0 1 1 0 1 1 1 * *
* * * * * * * *
PRESET CH+/PAGE▲(Previous)
RCKSK0410946
0 1 0 0 1 1 0 1 1 1 * *
* * * * * * * *
PRESET CH-/PAGE▼(Next)
RCKSK0410949 1 0 1 0 1 1 0 1 1 1 * * * * * * * * * * OPTION
RCKSK0410950 0 1 1 0 1 1 0 1 1 1 * * * * * * * * * * PAGE Previous
RCKSK0410951 1 1 1 0 1 1 0 1 1 1 * * * * * * * * * * PAGE Next
RCKSK0410956 0 0 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE REPEAT
RCKSK0410957 1 0 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE RANDOM/SHUFFLE
RCKSK0410958 0 1 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE USB DIRECT PLAY
RCKSK0410959 1 1 1 1 1 1 0 1 1 1 * * * * * * * * * * MAIN ZONE FAVORITE DIRECT PLAY
RCKSK0410970 0 1 0 1 0 0 1 1 1 1 * * * * * * * * * * MAIN ZONE TUNING UP
RCKSK0410971 1 1 0 1 0 0 1 1 1 1 * * * * * * * * * * MAIN ZONE TUNING DOWN
RCKSK0410972 0 0 1 1 0 0 1 1 1 1 * * * * * * * * * * MAIN ZONE PRESET CH UP
RCKSK0410973 1 0 1 1 0 0 1 1 1 1 * * * * * * * * * * MAIN ZONE PRESET CH DOWN
RCKSK0410976 0 0 0 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE Rewind
RCKSK0410977 1 0 0 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE BAND FM
RCKSK0410978 0 1 0 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE BAND AM
RCKSK0410979 1 1 0 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE Fast Forward
RCKSK0410983 1 1 1 0 1 0 1 1 1 1 * * * * * * * * * * MAIN ZONE SEARCH(RDS)
RCKSK0410992 0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE PLAY/PAUSE
RCKSK0410993 1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE STOP
RCKSK0410994 0 1 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE PAUSE
RCKSK0410995 1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE SKIP MINUS/ TUNING DOWN
RCKSK0410996 0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE SKIP PLUS/TUNING UP
RCKSK0410997 1 0 1 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE TUNING ▼
RCKSK0410998 0 1 1 0 0 1 1 1 1 1 * * * * * * * * * * MAIN ZONE TUNING ▲
ZONE2
REMOTE ID SET: 1
DENON CODE Parity GENRE1
GENRE2
４ ５ ２ ３ ０
4
3
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0
1 1 0 0
REMOTE ID SET: 2-4
DENON CODE Parity GENRE1
GENRE2
４ ５ ２ ３ ０
4
4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0
0 0 1 0
No.
Data ID parity
Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0430005 1 0 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE2 POWER ON/OFF
RCKSK0430006 0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE2 POWER ON
RCKSK0430007 1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE2 POWER OFF
RCKSK0430016 0 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY1
RCKSK0430017 1 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY2
RCKSK0430018 0 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY3
RCKSK0430019 1 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY4
RCKSK0430020 0 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY5
RCKSK0430021 1 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY6
RCKSK0430022 0 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY7
RCKSK0430023 1 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY8
RCKSK0430024 0 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY9
RCKSK0430025 1 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 KEY0
RCKSK0430027 1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR UP
RCKSK0430028 0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR DOWN
RCKSK0430029 1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR LEFT
RCKSK0430030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 CURSOR RIGHT
RCKSK0430031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE2 ENTER
RCKSK0430034 0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * ZONE2 RETURN
RCKSK0430036 0 0 1 0 0 1 0 0 0 0 * * * * * * * * * * ZONE2 MEMORY
RCKSK0430292 0 0 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 1
RCKSK0430293 1 0 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 2
RCKSK0430294 0 1 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 3
RCKSK0430295 1 1 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 4
RCKSK0430296 0 0 0 1 0 1 0 0 1 0 * * * * * * * * * * ZONE2 QUICK SELECT 5
RCKSK0430368 0 0 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME UP
RCKSK0430369 1 0 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME DOWN
RCKSK0430370 0 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VOLUME MUTE
RCKSK0430371 1 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET(MUTE)
RCKSK0430372 0 0 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET1(0dB)
RCKSK0430373 1 0 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET2(-20dB)
RCKSK0430374 0 1 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE2 VR PRESET3(-40dB)
RCKSK0430691 1 1 0 0 1 1 0 1 0 1 * * * * * * * * * * ZONE2 Internet Radio
RCKSK0430692 0 0 1 0 1 1 0 1 0 1 * * * * * * * * * * Main Zone Source CALL
RCKSK0430698 0 1 0 1 1 1 0 1 0 1 * * * * * * * * * * ZONE2 CD / PHONO
RCKSK0430699 1 1 0 1 1 1 0 1 0 1 * * * * * * * * * * ZONE2 Media Server
RCKSK0430704 0 0 0 0 0 0 1 1 0 1 * * * * * * * * * *
ZONE2 PHONO
RCKSK0430705 1 0 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 TUNER
RCKSK0430706 0 1 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 CD
RCKSK0430711 1 1 1 0 0 0 1 1 0 1 * * * * * * * * * * ZONE2 HEOS MUSIC
RCKSK0430715 1 1 0 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 TUNER
RCKSK0430716 0 0 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 HEOS MUSIC
RCKSK0430718 0 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 USB
RCKSK0430719 1 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE2 TUNER
RCKSK0430720 0 0 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 DVD
RCKSK0430721 1 0 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 Blu-ray
RCKSK0430722 0 1 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 TV AUDIO
RCKSK0430723 1 1 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 CBL/SAT
RCKSK0430725 1 0 1 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 GAME
RCKSK0430726 0 1 1 0 1 0 1 1 0 1 * * * * * * * * * * ZONE2 MEDIA PLAYER
RCKSK0430729 1 0 0 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 AUX1
RCKSK0430730 0 1 0 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 AUX2
RCKSK0430732 0 0 1 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 DVD/Blu-ray
RCKSK0430735 1 1 1 1 1 0 1 1 0 1 * * * * * * * * * * ZONE2 MEDIA PLAYER
RCKSK0430741 1 0 1 0 0 1 1 1 0 1 * * * * * * * * * * ZONE2 INTERNET RADIO(Recent Play)
RCKSK0430751 1 1 1 1 0 1 1 1 0 1 * * * * * * * * * * ZONE2 Bluetooth
RCKSK0430787 1 1 0 0 1 0 0 0 1 1 * * * * * * * * * * ZONE2 INPUT SOURCE SELECT Right
RCKSK0430788 0 0 1 0 1 0 0 0 1 1 * * * * * * * * * * ZONE2 INPUT SOURCE SELECT Left
RCKSK0430836 0 0 1 0 0 0 1 0 1 1 * * * * * * * * * * ZONE2 SLEEP
RCKSK0430945
1
0 0 0 1 1 0 1 1 1 * *
* * * * * * * *
PRESET CH+/PAGE▲(Previous)
RCKSK0430946
0 1 0 0 1 1 0 1 1 1 * *
* * * * * * * *
PRESET CH-/PAGE▼(Next)
RCKSK0430950 0 1 1 0 1 1 0 1 1 1 * * * * * * * * * * ZONE2 PAGE Previous
RCKSK0430951 1 1 1 0 1 1 0 1 1 1 * * * * * * * * * * ZONE2 PAGE Next
RCKSK0430956 0 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 REPEAT
RCKSK0430957 1 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 RANDOM/SHUFFLE
RCKSK0430958 0 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 USB DIRECT PLAY
RCKSK0430959 1 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE2 FAVORITE DIRECT PLAY
RCKSK0430970 0 1 0 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 TUNING UP
RCKSK0430971 1 1 0 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 TUNING DOWN
RCKSK0430972 0 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH UP
RCKSK0430973 1 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH DOWN
RCKSK0430976 0 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 Rewind
RCKSK0430977 1 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 BAND FM
RCKSK0430978 0 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 BAND AM
RCKSK0430979 1 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 Fast Forward
RCKSK0430983 1 1 1 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 SEARCH(RDS)
RCKSK0430992 0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PLAY/PAUSE
RCKSK0430993 1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 STOP
RCKSK0430994 0 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PAUSE
RCKSK0430995
1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP MINUS/TUNING DOWN
RCKSK0430996 0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP PLUS/TUNING UP
RCKSK0430997 1 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 TUNING ▼
RCKSK0430998 0 1 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 TUNING ▲
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
68

Denon AVR-X2500H Specifications

General

HDMI in	8
Composite video in	2
Ethernet LAN (RJ-45) ports	1
AirPlay	No
Display	-
Sample rate	196 kHz
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
RS-232 interface	Yes
Connectivity technology	Wired & Wireless
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions	3840 x 2160

Weight and Dimensions

Depth	340.3 mm
Width	434.3 mm
Height	167.6 mm
Weight	9389 g
