Denon AVR-X2600H User Manual

o
Example connections when using top middle speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with top middle speakers.
.
C
FL FR
SW
SL SR
TML TMR
0
Set “Assign Mode” to “Top Middle” in the menu. (v p. 187)
.
SW FLFR C SR SL TMR TML
Contents
Connections Playback Settings Tips Appendix
45
Front panel Display Rear panel Remote Index

Denon AVR-X2600H Specifications

General

Display	LCD
HDCP version	2.3
Product color	Black
Audio decoders	-
Volume control	Rotary
Audio amplifier	Yes
Amplifier output power	7 W
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
HDMI in	1
Certification	ISF
Power consumption (typical)	500 W
Receiver type	Surround
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W

Weight and Dimensions

Depth	237 mm
Width	434 mm
Height	341 mm
Weight	9500 g
