Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 205)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 205)
Playback speaker and zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel 2-channel (Pre-out) Can be set in all “Amp Assign” modes. 40
7.1-channel (surround back) 2-channel (Pre-out) Surround Back (Default) 41
7.1-channel (front height) 2-channel (Pre-out) Front Height 42
7.1-channel (top front) 2-channel (Pre-out) Top Front 43
7.1-channel (top middle) 2-channel (Pre-out) Top Middle 44
7.1-channel (front Dolby Atmos Enabled speaker) 2-channel (Pre-out) Front Dolby 45
7.1-channel (surround Dolby Atmos Enabled speaker) 2-channel (Pre-out) Surround Dolby 46
5.1-channel (bi-amp connection for front speaker) 2-channel (Pre-out) Bi-Amp 47
5.1-channel + second pair of front speaker 2-channel (Pre-out) Front B 48
5.1-channel
2-channel
(Speaker out)
ZONE2 49
0
The sound mode that can be selected varies according to the speaker configuration.
Contents Connections Playback Settings Tips Appendix
39
Front panel Display Rear panel Remote Index

Denon AVR-X2800H Specifications

General

Receiver type	stereo
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	LED
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Operating temperature (T-T)	5 - 35 °C
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, SBC
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, FM, MW
Internet radio services supported	-
HDMI in	6
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	341 mm
Width	434 mm
Height	237 mm
Weight	9500 g
