NETWORK connector
Used to connect to a LAN cable when connecting to a wired LAN network.
Digital audio connectors (DIGITAL AUDIO)
Used to connect devices equipped with digital audio connectors.
• TV equipped with an HDMI connector and incompatible with the ARC
(Audio Return Channel)” .
• TV equipped without an HDMI connector”.
• Set-top box (Satellite tuner/cable TV)” .
• DVD player or Blu-ray Disc player”
HDMI connectors
Used to connect devices equipped with HDMI connectors.
• TV equipped with an HDMI connector and compatible with the RC (Audio
Return Channel)”
• TV equipped with an HDMI connector and incompatible with the ARC (Audio
Return Channel)”
• Set-top box (Satellite tuner/cable TV)”
• DVD player or Blu-ray Disc player”
AC inlet (AC IN)
Used to connect the power cord.
TRIGGER OUT jack
Used to connect devices equipped with the trigger function.
