FM/AM antenna terminals (ANTENNA)
Used to connect FM antennas and AM loop antennas.
Analog audio connectors (AUDIO)
Used to connect devices equipped with analog audio connectors.
• “Connecting a set-top box (Satellite tuner/cable TV)”
• “Connecting a DVD player or Blu-ray Disc player”
Speaker terminals (SPEAKERS)
Used to connect speakers.
PRE OUT connectors
Used to connect a subwoofer with built-in amplifier or an external power amplifier.
• “Connecting the subwoofer”
• “Connection 3 : Connection using an external amplifier”
Component video connectors (COMPONENT VIDEO)
Used to connect devices equipped with component video connectors.
• “Connection 3 : TV equipped without an HDMI connector”
• “Connecting a set-top box (Satellite tuner/cable TV)”
• “Connecting a DVD player or Blu-ray Disc player”
NOTE
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
HOME
REMOTE CONTROL 1REAR PANEL 2
Rear Panel (3 of 3)
