Denon AVR-X3700H User Manual

Front Speaker
Set the front speaker A/B to use for every sound mode.
A
(Default):
Front speaker A is used.
B : Front speaker B is used.
A+B : Both front speakers A and B are used.
0
This can be set when “Assign Mode” is set to “7.1ch + Front B”. (v p. 217)
Speaker Preset
Two speaker settings can be saved to suit the environments where you
use your speakers.
For example, you can configure two presets easily to switch between
equalizer or speaker settings measured using Audyssey
®
Setup if the
characteristics of your room differ depending on factors such as whether
you use the screen.
If you want to use a preset, select the preset you want to use and then
configure settings such as Audyssey
®
Setup or the speaker settings to
save those settings to the preset you have selected.
Preset 1
(Default):
Saves the settings to Preset 1.
Preset 2: Saves the settings to Preset 2.
0
The following settings are saved to presets.
0
“Amp Assign” settings
0
“Speaker Config.” settings
0
“Distances” settings
0
“Levels” settings
0
“Crossovers” settngs
0
“Bass” settings
0
“Front Speaker” settings
0
“MultEQ
®
XT32” data
0
“Graphic EQ” data
0
This setting also be configured using “Speaker Preset” in the option menu.
(v p. 131)
Contents Connections Playback Settings Tips Appendix
230
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
