Levels
Set the volume of the test tone to be the same at the listening position
when it is output from each speaker.
o
Test Tone Start
A test tone is output from the selected speaker.
While listening to the test tone, adjust the volume output from the
selected speaker.
–12.0 dB – +12.0 dB (Default : 0.0 dB)
0
The set “Levels” are reflected in all sound modes.
0
If you wish to adjust the channel level for each input source, carry out the
settings in “Channel Level Adjust”. (v p. 118)
0
When headphones are connected to the PHONES connector on this unit, you
cannot set “Levels”.
o
Set Defaults
The “Levels” settings are returned to the default settings.
Crossovers
Set in accordance with the lower limit frequency of the base frequencies
that can be played back through each speaker. See the speaker manual
for information concerning speaker crossover frequency.
o
Set the crossover frequency
40 Hz / 60 Hz / 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz /
180 Hz / 200 Hz / 250 Hz (Default: 80 Hz)
0
“Crossovers” can be set when the “Subwoofer Output” setting is “LFE + Main”,
or when you have a speaker that is set to “Small”. (v p. 225)
0
The default crossover frequency is “80 Hz”, which will work best with the
widest variety of speakers. We recommend setting to a higher frequency that
the crossover frequency when small speakers are used. For example, set to
“250 Hz” when the frequency range of the speakers is 250 Hz – 20 kHz.
0
Sound below the crossover frequency is cut off from the output of the
speakers set in “Small”. This cut off bass frequency is output from the
subwoofer or front speakers.
0
The speakers that can be set differ depending on to the “Subwoofer Output”
setting. (v p. 225)
0
When “LFE” is selected, speakers set to “Small” at “Speaker Configuration”
can be set. If the speakers are set to “Large”, “Full Band” is displayed and
the setting cannot be made. (v p. 214)
0
When “LFE + Main” is selected, speakers can be set regardless of the
“Speaker Configuration” setting. (v p. 214)
0
The audio settings in “IMAX Audio Settings” are applied during IMAX
playback. (v p. 166)
Contents
Connections Playback Settings Tips Appendix
224
Front panel Display Rear panel Remote Index
