Denon AVR-X3800H User Manual

q
e
wr
q
A
Bluetooth/wireless LAN antenna connectors
Used to connect the included external antennas for Bluetooth/wireless
connectivity when connecting to a network via wireless LAN, or when
connecting to a handheld device via Bluetooth. (v p. 70)
A
Place the external antennas for Bluetooth/wireless connectivity
evenly over the screw terminal of rear.
B
Turn clockwise until the antennas is fully connected.
C
Rotate the antenna upwards for best reception.
qwe
B
TRIGGER OUT jack
Used to connect devices equipped with the trigger function.
(v p. 72)
C
Digital audio connectors (DIGITAL AUDIO)
Used to connect devices equipped with digital audio connectors.
0
“Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC / eARC” (v p. 59)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 61)
0
“Connecting a media player” (v p. 62)
D
RS-232C connector
Used to connect home automation controller devices fitted with
RS-232C connectors. Consult the owner’s manual of the home
automation controller for more information about serial control of this
unit.
Perform the operation below beforehand.
A
Turn on the power of this unit.
B
Turn off the power of this unit from the external controller.
C
Check that the unit is in the standby mode.
Contents Connections Playback Settings Tips Appendix
25
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
