Denon AVR-X3800H User Manual

yt
i
u
o
E
REMOTE CONTROL jacks
Used to connect infrared receivers/transmitters in order to operate this
unit and external devices from a different room. (v p. 71)
F
NETWORK connector
Used to connect to a LAN cable when connecting to a wired LAN
network. (v p. 69)
G
SIGNAL GND terminal
Used to connect a ground wire for the turntable. (v p. 65)
H
HDMI connectors
Used to connect devices equipped with HDMI connectors.
0
“Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC / eARC” (v p. 58)
0
“Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC / eARC” (v p. 59)
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 61)
0
“Connecting a media player” (v p. 62)
0
“Connecting a Blu-ray Disc player or DVD player” (v p. 63)
0
“Connecting a game console or player device compatible with
8K” (v p. 64)
I
PRE OUT connectors
Used to connect a subwoofer with built-in amplifier or an external power
amplifier.
0
“Connecting the subwoofer” (v p. 39)
0
“Connecting an external power amplifier” (v p. 43)
0
“Connection 3 : Connection using an external amplifier
(ZONE2)” (v p. 153)
Contents
Connections Playback Settings Tips Appendix
26
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
