Denon AVR-X3800H User Manual

Connecting 7.1-channel speakers: Second pair of front speakers
This system enables switching playback between front speakers A and B as desired.
You can connect speakers for up to 9-channels for MAIN ZONE. When you connect speakers for 8 or more channels, the output speakers automatically
switch according to the input signal and sound mode.
FHL
SW
C
SL
SBL
FHR
SR
SBR
FLFL
(B) (A)
FRFR
(A) (B)
SBR SBL
CSRSL
SW
FR
(A)
FL
(A)
FHR FHL
zz
FR
(B)
FL
(B)
z
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers can
be connected to the HEIGHT1 speaker terminals. Set the speaker to be
connected from “Height” - “Layout” in the menu. (v p. 208)
Contents
Connections Playback Settings Tips Appendix
54
Front panel Display Rear panel Remote Index

Denon AVR-X3800H Specifications

General

Channels	9.4
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Yes (Amazon Alexa, Google Assistant, Apple Siri)
eARC	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Ethernet	Yes
Phono Input	Yes
AM/FM Tuner	Yes
Audyssey Room Correction	Audyssey MultEQ XT32
HDR Compatibility	HDR10+, Dolby Vision, HLG
Streaming	Spotify, Tidal
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
USB Port	Yes
Signal-to-Noise Ratio	100 dB (IHF-A weighted, Direct mode)
