o
Crossover
Set the maximum frequency of the bass signal output from each
channel to the subwoofer.
40 Hz / 60 Hz / 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz /
200 Hz / 250 Hz (Default: 80 Hz)
0
This can be set when “2ch Playback” - “Subwoofer” is set to “Yes”.
0
When “2ch Playback” - “Front” is set to “Large” and “SW Mode” is set to “LFE”,
“Full Band” is displayed and this cannot be set.
o
Distance FL / Distance FR
Set distance from main listening position to speaker.
0.0 ft – 60.0 ft (Default: 12.0 ft) /
0.00 m – 18.00 m (Default: 3.60 m)
0
Set the difference in the distance between the speakers to less than 20.0 ft
(6.00 m).
o
Level FL / Level FR
Adjust the level of each channel.
-12.0 dB – +12.0 dB (Default: 0.0 dB)
Contents Connections Playback Settings Tips Appendix
240
Front panel Display Rear panel Remote Index
