Denon AVR-X4500H User Manual

o
Subwoofer
Set the presence of a subwoofer.
Yes
(Default):
Use a subwoofer.
No:
Select when a subwoofer is not
connected.
0
When “Speaker Config.” - “Subwoofer” in the menu is set to “None”, No is
automatically set. (v
p. 229)
If the “Front” setting is “Small”, the setting is automatically “Yes”.
o
SW Mode
Select low range signals to be reproduced by subwoofer.
LFE
(Default):
When “2ch Playback” - “Front” is set to
“Large”, only LFE signals are output from
the subwoofer. Also, when “2ch
Playback” - “Front” is set to “Small”, the
front channel low range signals are
added to the LFE signals and output from
the subwoofer.
LFE+Main:
The front channel low range signal is
added to the LFE signal output from the
subwoofer.
0
This can be set when “2ch Playback” - “Subwoofer” is set to “Yes”.
Contents Connections Playback Settings Tips Appendix
239
Front panel Display Rear panel Remote Index

Denon AVR-X4500H Specifications

General

Display	-
Quantity	1
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Audio amplifier	Yes
Multi-Zone quantity	3
Connector contacts plating	Gold
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	125 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in	8
Audio (L/R) in	5
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
