Denon AVR-X4800H User Manual

o
Floor
n
Layout
Select the floor speakers location.
5ch & SB
(Default):
This layout combines a surround back
speaker with the basic 5-channel layout.
5ch：
This is a basic 5-channel layout that uses
front speakers, center speakers and
surround speakers.
o
Height
n
Height Sp
Select the number of the height speakers and ceiling speakers used in
MAIN ZONE.
None: Uses no height and ceiling speakers.
2ch:
Uses a set of (two) height speakers or
ceiling speakers.
4ch
(Default):
Uses two sets of (four) height speakers or
ceiling speakers.
5ch:
Uses five height speakers
z
z
If “5ch” is selected, connect the Top Surround speaker to the SUBWOOFER 2
terminal.
n
Dolby Sp
Select the number of the Dolby Atmos Enabled speakers used in MAIN
ZONE.
None
(Default):
Uses no Dolby Atmos Enabled speakers.
2ch:
Uses a set of (two) Dolby Atmos Enabled
speakers.
4ch:
Uses two sets of (four) Dolby Atmos
Enabled speakers.
Contents Connections Playback Settings Tips Appendix
228
Front panel Display Rear panel Remote Index

Denon AVR-X4800H Specifications

General

Channels	9.4
Dolby Atmos	Yes
DTS:X	Yes
HDMI Inputs	7
HDMI Outputs	3
4K/120Hz Pass-through	Yes
8K Support	Yes
Wi-Fi	Yes (2.4GHz/5GHz)
Bluetooth	Yes
HEOS Built-in	Yes
Amplifier Channels	9
Power Output per Channel @ 8 Ohms / 1 kHz / 0.08% THD / 2 Channels Driven	125W
Speaker Impedance	4-16 Ohms
Auro 3D	Yes
IMAX Enhanced	Yes
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Phono Input	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Audyssey MultEQ XT32	Yes
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Network Connectivity	Ethernet, Wi-Fi
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	13.5 kg
Power Output per Channel	125W
Voice Control	Yes
Frequency Response	10 Hz - 100 kHz
DAC	32-bit AKM
Video Pass-Through	8K
Zone Audio Output	Zone 2, Zone 3
Wireless Audio Streaming	Yes
Signal-to-Noise Ratio	102 dB
Video Inputs/Outputs	7/3 (HDMI)
Audio Inputs/Outputs	7 HDMI inputs, 3 HDMI outputs, 1 phono input, 2 optical inputs, 1 coaxial input
