Layout
Select the height, ceiling, or Dolby Atmos Enabled speaker location.
The layouts that can be selected differ depending on the combinations of “Assign Mode” and “Floor” - “Layout” in the menu. (“ Assign
Mode ” (v
p. 225), “Floor” - “ Layout ” (v p. 228))
Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Layout HEIGHT 1 HEIGHT 2
None None - - -
2ch None
Front Height Front Height -
Top Front Top Front -
Top Middle Top Middle -
Top Rear Top Rear -
Rear Height Rear Height -
4ch None
z 1
Front Height & Top Middle Front Height Top Middle
Front Height & Top Rear Front Height Top Rear
Front Height & Rear Height z 2
Front Height Rear Height
Front Height & Surr. Height Front Height Surr. Height
Top Front & Top Rear (Default) Top Front Top Rear
Top Front & Rear Height Top Front Rear Height
Top Middle & Rear Height Top Middle Rear Height
None 2ch
Front Dolby Front Dolby -
Surround Dolby Surround Dolby -
Back Dolby z 3
Back Dolby -
z1
This can be selected when “Assign Mode” is set to “11.1ch” or “9.1ch” in the menu.
z2
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup
in place of Surround Height speakers.
z3
This can be selected when “Assign Mode” is set to “11.1ch” or “9.1ch” and “Floor” - “Layout” is set to “5ch & SB” in the menu.
Contents
Connections Playback Settings Tips Appendix
229
Front panel Display Rear panel Remote Index

Denon AVR-X4800H Specifications

General

Channels	9.4
Dolby Atmos	Yes
DTS:X	Yes
HDMI Inputs	7
HDMI Outputs	3
4K/120Hz Pass-through	Yes
8K Support	Yes
Wi-Fi	Yes (2.4GHz/5GHz)
Bluetooth	Yes
HEOS Built-in	Yes
Amplifier Channels	9
Power Output per Channel @ 8 Ohms / 1 kHz / 0.08% THD / 2 Channels Driven	125W
Speaker Impedance	4-16 Ohms
Auro 3D	Yes
IMAX Enhanced	Yes
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Phono Input	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Audyssey MultEQ XT32	Yes
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Network Connectivity	Ethernet, Wi-Fi
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	13.5 kg
Power Output per Channel	125W
Voice Control	Yes
Frequency Response	10 Hz - 100 kHz
DAC	32-bit AKM
Video Pass-Through	8K
Zone Audio Output	Zone 2, Zone 3
Wireless Audio Streaming	Yes
Signal-to-Noise Ratio	102 dB
Video Inputs/Outputs	7/3 (HDMI)
Audio Inputs/Outputs	7 HDMI inputs, 3 HDMI outputs, 1 phono input, 2 optical inputs, 1 coaxial input
