FDL FDR
BDL BDR
SDL SDR
FDL/FDR
(Front Dolby speaker
left/right):
Place the FRONT Dolby Atmos Enabled speaker
on the front speaker. For a Dolby Atmos Enabled
integrated with a front speaker, place the Dolby
Atmos Enabled speaker instead of the front
speaker.
SDL/SDR
(Surround Dolby
speaker left/right):
Place the SURROUND Dolby Atmos Enabled
speaker on the surround speaker. For a Dolby
Atmos Enabled speaker integrated with a surround
speaker, place the Dolby Atmos Enabled speaker
instead of the surround speaker.
BDL/BDR
(Back Dolby speaker
left/right):
Place the BACK Dolby Atmos Enabled speaker on
the surround back speaker. For a Dolby Atmos
Enabled speaker integrated with a surround back
speaker, place the Dolby Atmos Enabled speaker
instead of the surround back speaker.
About Dolby Atmos Enabled speakers
Dolby Atmos Enabled speakers reflect the sound off the ceiling to allow
the sound to come from over your head by using a special upward-
pointing speaker that is placed on the floor.
You can enjoy the Dolby Atmos 3D sound even in an environment where
speakers cannot be installed on the ceiling.
.
Contents
Connections Playback Settings Tips Appendix
35
Front panel Display Rear panel Remote Index

Denon AVR-X4800H Specifications

General

Channels	9.4
Dolby Atmos	Yes
DTS:X	Yes
HDMI Inputs	7
HDMI Outputs	3
4K/120Hz Pass-through	Yes
8K Support	Yes
Wi-Fi	Yes (2.4GHz/5GHz)
Bluetooth	Yes
HEOS Built-in	Yes
Amplifier Channels	9
Power Output per Channel @ 8 Ohms / 1 kHz / 0.08% THD / 2 Channels Driven	125W
Speaker Impedance	4-16 Ohms
Auro 3D	Yes
IMAX Enhanced	Yes
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Phono Input	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Audyssey MultEQ XT32	Yes
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Network Connectivity	Ethernet, Wi-Fi
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	13.5 kg
Power Output per Channel	125W
Voice Control	Yes
Frequency Response	10 Hz - 100 kHz
DAC	32-bit AKM
Video Pass-Through	8K
Zone Audio Output	Zone 2, Zone 3
Wireless Audio Streaming	Yes
Signal-to-Noise Ratio	102 dB
Video Inputs/Outputs	7/3 (HDMI)
Audio Inputs/Outputs	7 HDMI inputs, 3 HDMI outputs, 1 phono input, 2 optical inputs, 1 coaxial input
