Denon AVR-X6700H Quick Start Guide

7
3) Connect the receiver to your TV with
an HDMI cable
HEIGHT3 HEIGHT3
(ARC/eARC)
HDMI IN
HDMI OUT
MONITOR 1
(ARC/eARC)
HDMI cable
Receiver (Rear panel)
ARC (Audio Return Channel) and eARC (Enhanced Audio
Return Channel) support:
If your TV supports ARC, your TV can send audio back to the AV receiver
when you are using your TV’s built-in video sources (TV tuner, Smart TV
streaming services, etc.) ARC requires that you enable HDMI CEC on your
TV. Please refer to your TV’s Owner’s Manual for instructions on how to
setup HDMI CEC. In addition, if your TV supports eARC, it can also send
back high bitrate audio formats such as Dolby TrueHD, Dolby Atmos,
DTS-HD Master Audio and DTS:X. Please refer to your TV’s Owner’s
Manual for additional information about enabling the eARC function.
4) Turn on the TV
TV remote control unit
5) Select the appropriate HDMI input on
your TV
HDMI
or
TV/
VIDEO
INPUT
TV remote control unit
PrintingColor:Black

Denon AVR-X6700H Specifications

General

Channels	11.2
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200mV / 47k ohms
HDMI Inputs	8
HDMI Outputs	3
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Video Upscaling	8K
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Zone Audio Output	3 Zones
Room Calibration	Audyssey MultEQ XT32
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05%
Signal-to-Noise Ratio	102dB
HDMI Support	4K/120Hz, 8K/60Hz
USB Port	1
Streaming Services	AirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio Decoding	Dolby Atmos, DTS:X, Auro-3D
