o
ZONE2/3
When “Amp Assign” is “9.1ch + ZONE2/3-MONO”, the speaker
terminal used for the ZONE2/3 speakers is displayed. Depending on
the settings of Main Zone speaker configuration, the terminal is
determined automatically.
HEIGHT 3/FRONT WIDE:
The HEIGHT 3/FRONT WIDE speaker
terminal is used for the ZONE2/3
speakers.
HEIGHT 2:
The HEIGHT 2 speaker terminal is used
for the ZONE2/3 speakers.
HEIGHT 1:
The HEIGHT 1 speaker terminal is used
for the ZONE2/3 speakers.
o
View Terminal Config.
This shows how to connect the speaker terminals and PRE OUT
connectors for your “Speaker Layout” setting on the menu screen.
