DCM-390/290/27/500AE
BUFFER P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D 941 0048 909 IC(SCF5249LPV120/SCF5249LAG120)
417-MCDS4-736
1
IC202 00D 941 0049 005
IC(K4S641632E-TC/K4S641632F/
K4S641632H-TC75)
417-CDN88-501
1
IC203 00D 941 0049 102 BUFFER IC ASS'Y (M29W800DB70N6Y)
for 390BKE3/290BKE3/27BKE3
704-390-6144
1*
IC203 00D 941 0053 004 BUFFER IC ASS'Y (M29W800DB70N6Y)
for 500AEBKE2/500AESPE2
704-C200-6660
1*
IC204 00D 941 0049 209 IC(BA18BC0FP-E2)
417-MCDS4-737
1
RESISTORS GROUP
R189,190 - CHIP RESISTOR (220K OHM,1/10W)
412-CDVD2001-521
2
R191 - CHIP RESISTOR (47K OHM,1/10W)
412-CDVD2001-532
1
R201 - CHIP RESISTOR (220K OHM,1/10W)
412-CDVD2001-521
1
R204-206 - CHIP RESISTOR (220K OHM,1/10W)
412-CDVD2001-521
3
R215,216 - CHIP RESISTOR (4.7K OHM,1/10W)
412-CDVD2001-523
2
R202,203 - CHIP RESISTOR (4.7K OHM,1/10W)
412-CDVD2001-523
2
R210,211 - CHIP RESISTOR (100 OHM,1/10W)
412-CDVD2001-530
2
R213 - CHIP RESISTOR (100 OHM,1/10W)
412-CDVD2001-530
1
R220,221 - CHIP RESISTOR (100 OHM,1/10W)
412-CDVD2001-530
2
R207,208 - CHIP RESISTOR (0 OHM,1/10W)
412-CDVD2001-552
2
R222-228 - CHIP RESISTOR (0 OHM,1/10W)
412-CDVD2001-552
7
R231 - CHIP RESISTOR (10K OHM,1/10W)
412-CDVD2001-534
1
R236 - CHIP RESISTOR (10K OHM,1/10W)
412-CDVD2001-534
1
CAPACITORS GROUP
C201-214 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
14
C216 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C217 - ELEC.CAPACITOR (100uF/10V)
413-HMA2200-5017
1
C218-221 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
4
C222 - ELEC.CAPACITOR (220uF/10V)
413-HT801K-192
1
C223 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C226 - CHIP CAPACITOR (0.01uF/50V)
413-DCM280-771
1
C227 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C229 - CHIP CAPACITOR (0.01uF/50V)
413-DCM280-771
1
C230 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C232 - CHIP CAPACITOR (0.01uF/50V)
413-DCM280-771
1
C233 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C235,236 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
2
C237 - ELEC.CAPACITOR (100uF/10V)
413-HMA2200-5017
1
C238 - CHIP CAPACITOR (150pF/50V)
413-900-931
1
C239 - CHIP CAPACITOR (39pF/50V)
413-390-987
1
OTHER PARTS GROUP
CN106A 00D 941 0049 306 13P FFC CONNECTOR
404-385-2086
1*
CN107A 00D 941 0049 403 30P FFC CONNECTOR
404-385-2088
1*
CN302 nsp 00D 941 0049 500 2P SOCKET
404-KMD1500-608
1
L201,202 -
BEAD CORE (RH03506ST-B,65
Ω
/100MHz)
415-HV3500K-090
1
-
CUSHON
612-390-235
1*
2
