31
DCM-390/290/27/500AE
PHONE P.W.B. UNIT ASS'Y
PHOTO TRANSISTOR P.W.B. UNIT ASS'Y
INFERARED EMITTING P.W.B. UNIT ASS'Y
AC JACK P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
CAPACITORS GROUP
C309 - CHIP CAPACITOR (0.1ÉþF/50V)
413-DCM280-773
1
C313,314 - CHIP CAPACITOR (470pF/50V)
413-007USB-786
2
OTHER PARTS GROUP
W301 00D 941 0049 704 3P 2.5 CONNECTOR WIRE (L=400)
404-390-2166
1*
JK301 00D 958 0018 102 3P PHONE JACK
420-DCM270X-062
1
L301-303 00D 958 0016 900 BEAD CORE(86-019-A)
415-HV3500K-090
3
CHASSIS - GROUND WIRE (L=60)
406-390-827
1*
- 1P GROUND WIRE (L=80)
406-HV3500K-408
1
00D 941 0050 803 EMI CORE
415-390-277
1*
Ref. No. nsp Part No. Part Name Remarks Q'ty New
Q01 00D 958 0018 209 PHOTO TRANSISTOR(LTR-301)
416-DCM270X-120
1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
D01 00D 958 0018 403
INFERARED EMITTING DIODE(LTE-4206C)
410-DCM270X-132
1
R01 -
CARBON FILM RESISTOR (390K OHM,1/6W)
412-3113-076
1
00D 958 0021 005 ROUND PLASTIC SPACER(302A)
605-DCM270-055
1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
00D 941 0049 801 AC SOCKET
for 390BKE3/290BKE3/
27BKE3
404-DJ2-021
1*
00D 941 0050 405 AC SOCKET
for 500AEBKE2/500AESPE2
404-HDJ2200E-969
1*
-FUSE CLIPS
420-KT350A-004
2
00D 958 0016 900 BEAD CORE(86-019-A)
415-HV3500K-090
2
! FUSE01 00D 941 0049 908 FUSE(1A/250V) for 390BKE3/290BKE3/
27BKE3
422-CDN12F-028
1
! FUSE01 00D 941 0050 007 FUSE(T1AL/250V) for DCM500AEBKE2/
DCM500AESPE2
422-HDJ7100-022
1
- FUSE COVER
504-DJ2500J-046
1
