4
DCM-390/290/27/500AE
DISASSEMBLY
(To reassemble, reverse disassembly)
1. TOP COVER
Remove 4 screws A fixing the Top
Cover and 5 screws A mounting the
Rear Panel, then detach the Top Cover
as shown in the arrow direction.
A
A
A
2. BACK PANEL
Remove 3 screws B mounting the
Bottom Cover and 5 screws C mounting
the Back Panel, then detach the Back
Panel as shown in the arrow direction.
Note: Only in 3x5mm, other screws
can’t be used for B .
Note: Do not yet exclude FFC (☆mark)
DCM390BKE3
ONLY
C
C
B
☆
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
