5
DCM-390/290/27/500AE
4. CONTROL P.W.B. & Phone P.W.B.
Remove 8 screws E mounting the
Front Panel and 1 E screw fixing the
Control P.W.B., then detach the Control
P.W.B. as shown in the arrow direction.
Remove 2 screws F mounting the
Front Panel fixing the Phone P.W.B.,
then detach the Phone P.W.B..
3. FRONT PANEL
Remove 2 side screws D and 5 below
screws B mounting the Front Panel, t
hen detach the Front Panel as shown
in the arrow direction.
5. LOADER ASS’Y & MAIN P.W.B.
Remove 1 screw G and 4 screws H
mounting the Bottom Cover, then detach
the Loader Ass'y & Main P.W.B. as shown
in the arrow direction.
F
E
E
E
Note: Do not yet exclude FFC (☆mark)
Note: Do not yet exclude FFC (☆mark)
B
D
D
☆
GH
H
H
H
☆
