6
DCM-390/290/27/500AE
7. MAIN P.W.B.
Remove 2 screws I , 4 screws J , 1
screw K fixing the Main P.W.B. then
detsch the Main P.W.B. as shown in
the arrow direction.
6. LASER SHORT
Reverse a Loader ass'y & Main P.W.B. unit
and a Laser short-circuit in Pick-up next.
I
J
K
I
J
LESER
SHORT
