Denon DN-2700F - CONTROL PANEL LAYOUT; DN-2700 F Main Unit Front Panel Controls; RC-37 Control Unit Front Panel Controls

DN-2700F MAIN UNIT
FRONT PANEL
Figure 1
RC-37 CONTROL UNIT
FRONT PANEL
Figure 2
DN-2700F FRONT PANEL
POWER (Power ON/OFF Switch)
POWER (Power On Indicator)
Disc Holder
NO DISC (No Disc Indicator)
CUE (Cue Indicator)
PLAY/PAUSE (Play/Pause Indicator)
OPEN/CLOSE (Open/Close Button)
RC-37 FRONT PANEL
LCD (Liquid Crystal Display)
TIME (Time Button)
OPEN/CLOSE (Open/Close Button)
CONT./SINGLE (Continue/ Single Button)
LOOP (Loop Button)
FINE (Fine Search Button)
Shuttle Dial
Jog Dial
6
