13DN-C680
Note:
FS unit:FS converter unit(ACD25,option)
Ext.sync.unit:External video synchronizing unit(ACD27CS,Option)
91 I/O KI0 I Pu Key matrix data bus
92 I/O KI1 I Pu Key matrix data bus
93 I/O KI2 I Pu Key matrix data bus
94 I/O KI3 I Pu Key matrix data bus
95 I/O KI4 I Pu Key matrix data bus
96 I/O KI5 I Pu Key matrix data bus
97 I/O KI6 I Pu Key matrix data bus
98 I/O KI7 I Pu Key matrix data bus(Not used)
99 I/O,GCK8 I/O - - Not used. Open
100 VCC VCC - - Power supply(+3.3V)
Pin
No.
Port Name Symbol I/O Ext Note
