12
12DN-C680
36 I/O(-INIT) -INIT O Pu FPGA(XCS05XL) control signal:-INIT
37 VCC VCC - - Power supply(+3.3V)
38 GND GND - - GND(0V)
39 I/O PDI5 I Pu Parallel port 'L':Forward search command input
40 I/O PDI6 I Pu Parallel port 'L':Reverse search command input
41 I/O PDI7 I Pu Parallel port 'L':Fader start command input
42 I/O PDI8 I Pu Parallel port(Reserved)
43 I/O PDI9 I Pu Parallel port(Reserved)
44 I/O PDI10 I Pu Parallel port(Reserved)
45 I/O -CLOSE O Pu Loading motor driver(BA6287) control signal 'L':Close
46 I/O -OPEN O Pu Loading motor driver(BA6287) control signal 'L':Open
47 I/O -LIMITSW+ I Pu Laser pickup position status signal 'L':pickup is most inside position
48 I/O,GCK4 -LDIN I Pu Loading status singal 'L':Close operation finished
49 GND GND - - GND(0V)
50 DONE DONE O Pu FPGA(XCS05XL) control signal:DONE
51 VCC VCC - - Power supply(+3.3V)
52 -PROGRAM -PGM I Pu FPGA(XCS05XL) control signal:-PROGRAM
53 I/O(D7) -LDOUT I Pu Loading status singal 'L':Open operation finished
54 I/O,GCK5 -JOG0 I Pu Jog dial status detect signal
55 I/O(D6) -JOG1 I Pu Jog dial status detect signal
56 I/O -SHTL0 I Pu Shuttle status detect signal
57 I/O(D5) -SHTL1 I Pu Shuttle status detect signal
58 I/O -SHTL2 I Pu Shuttle status detect signal
59 I/O -SHTL3 I Pu Shuttle status detect signal
60 I/O -TRSLC I Pu Select knob status signal
61 I/O(D4) -PUSH I Pu Select button(PUSH) status signal
62 I/O AMUTE O Pu Analog Audio control signal:Mute 'H':Mute
63 VCC VCC - - Power supply(+3.3V)
64 GND GND - - GND(0V)
65 I/O(D3) DMUTE O Pu Digital Audio control signal:Mute 'H:Mute
66 I/O FSI0 O Pu X'tal(8.192MHz for FS converter unit) control signal:Enable 'L':Enable
67 I/O FSI1 O Pu X'tal(12.288MHz for FS converter unit) control signal:Enable 'L':Enable
68 I/O(D2) SEL0 O - Key matrix scan signal
69 I/O SEL1 O - Key matrix scan signal
70 I/O(D1) SEL2 O - Key matrix scan signal
71 I/O DYCON O Pu Serial Driver(HD26LS31) control signal:Enable 'H':Enable
72 I/O(D0,DIN) DIN I - FPGA(XCS05XL) control signal:DIN
73 I/O,GCK6(DOUT) I/O - - Not used. Open
74 CCLK CCLK I - FPGA(XCS05XL) control signal:CCLK
75 VCC VCC - - Power supply(+3.3V)
76 O,TDO O O - Not used. Open
77 GND GND - - GND(0V)
78 I/O -TRRST0 O Pd DIT(YM3437) and FS unit control signal:Reset 'L':Reset
79 I/O,GCK7 V/-W O Pd PLL circuit of Ext.sync.unit control signal
80 I/O(CS1) FSNOO O Pd Digital audio control signal:Data select 'L':DSP data 'H':FS unit data
81 I/O FSSEL O Pd FS unit control signal:FSSEL 'L':FS=32kHz 'H':FS=48kHz
82 I/O -FSIN I Pu FS unit status signal 'L':FS unit detected
83 I/O -SUBON O - Digital audio control signal:Subcode ON/OFF
84 I/O -SMIN I Pu Ext.sync.unit status signal 'L':Ext.sync.unit detected
85 I/O -CLKIN I Pu Ext.sync.unit status signal 'L':Video/word clock detected
86 I/O PITCH O Pd Not used. Open
87 I/O GSEL O - RF amprifier gain control signal
88 GND GND - - GND(0V)
89 VCC VCC - - Power supply(+3.3V)
90 I/O CKSEL O - Master clock(384FS) control signal 'L':Ext.sync.unit
Pin
No.
Port Name Symbol I/O Ext Note
