DN-S1000
Note) Pins marked with an asterisk can be switched to different signals by using microcontroller commands.
73 MDATA I µcom command data signal input
74 MLD I µcom command load signal input
75 *STAT O Status signal output
76 *BLKCK O Subcode block clock signal output
77 *SMCK O 4.2336MHz/8.4672MHz clock signal output
78 *PMCK O 88.2kHz clock signal output
79 *TX O Digital audio interface signal output
80 *FLAG O Flag signal output
81 NRST I LSI reset signal input
82 NTEST I Test mode setup input
83 DVSS3 I GND 3 for digital circuits
84 X1 I Crystal oscillator circuit input
85 X2 O Crystal oscillator circuit output
86 IOVDD2 I Power supply 2 for digital I/O
87 DVDD2 I Power supply 2 for inside digital circuits
88 D2 I/O SDRAM data signal I/O 2
89 D1 I/O SDRAM data signal I/O 1
90 D0 I/O SDRAM data signal I/O 0
91 D3 I/O SDRAM data signal I/O 3
92 D4 I/O SDRAM data signal I/O 4
93 D5 I/O SDRAM data signal I/O 5
94 D6 I/O SDRAM data signal I/O 6
95 D7 I/O SDRAM data signal I/O 7
96 D15 I/O SDRAM data signal I/O 15
97 D14 I/O SDRAM data signal I/O 14
98 DRVDD2 I Power supply 2 for SDRAM interface I/O
99 D13 I/O SDRAM data signal I/O 13
100 D12 I/O SDRAM data signal I/O 12
