Appendix (English)
Technical Specifications
Specifications are subject to change without notice.
Mono Input
Channels
Microphone inputs: Electronically balanced, discrete input configuration
Frequency response: 20 Hz to 20 kHz, +0.5 dB
THD+N: <0.005% at 0 dBu, 1 kHz
Gain range: 0 dB to 45 dB (Mic)
SNR: 105 dB
Line Inputs
Electronically balanced
Frequency response: 20 Hz to 20 kHz, +0.25 dB
THD+N: <0.005% at 0 dBu, 1 kHz
Sensitivity range: -15 dBu to 30 dBu
Impedances
Microphone inputs: 51.1
K
Ω
Channel insert return: 200 KΩ
All other inputs: >100 KΩ
2-Track outputs: 10 KΩ
All other outputs: 20 KΩ
Equalization
High-shelving: ±15 dB @ 12 kHz
Mid-bell (mono): ±15 dB @ 2.5 kHz
Low-shelving: ±15 dB @ 80 Hz
Main EQ: 9 EQ bands (63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4 kHz,
8 kHz, 16 kHz), ±15 dB
DSP
(DFX/Effects)
A/D & D/A converters: 24-bit
DSP Resolution: 24-bit
Effects: 10 DSP effects families with 10 variations available per family
Presets: 100 total
Controls: Rotary encoder preset selector, DSP mute switch, peak LED
indicator
Main Mix
Noise (bus noise): -102 dBr (ref: +4 dBu, fader 0 dB, channels muted)
-91 dBr (ref: +4 dBu, fader 0 dB, all input channels
assigned and set to “unity” gain)
Phantom Power: Mic Pin2/Pin3 and Pin1 47±2V
