4
Features
Top Panel
1
2
2
2
3
1
2
2
2
3
55
6
7
89
44
37
38
36
10
11 11 11 11
7
89
10
11 11 11 11
12
13
13
18
20 20 20
22 23 24 25
26
28 29
30
31
32
33
33
34 35
2727
21
18 18 19 18
20 20 20
22 23 24 25
21
18 18 19
14
12
14
15
17
15
17
16 16
1. Channel Level: Turn this knob to adjust the level of the pre-fader, pre-EQ audio signal for
the channel.
2. Channel EQ: Turn these knobs to boost or cut the high, mid-range, and low frequencies
for the channel.
3. Channel Filter: Turn this knob to adjust the filter applied to the channel. Turn the knob
counterclockwise to apply a low-pass filter. Turn the knob clockwise to apply a high-pass filter.
4. Channel Cue: Press this button to send the channel’s pre-fader signal to the headphones’
cue channel.
5. Channel Fader: Use this fader to adjust the channel’s volume level.
6. Crossfader: Use this crossfader to mix between the two decks.
7. Shift: Press and hold this button to access secondary functions of other controls.
8. Sync / Sync Off: Press this button to automatically match the corresponding Deck’s tempo
with the opposite Deck’s tempo and phase.
Press and hold Shift and press this button to deactivate Sync.
9. Cue / Track Start: During playback, press this button to return the track to a temporary
cue point. If you have not set a temporary cue point, then press this button to return to the
start of the track. (To set a temporary cue point, make sure the track is paused, move the
platter to place the audio playhead at the desired location, and then press this button.)
If the deck is paused, press and hold this button to play the track from the temporary cue
point. Release the button to return the track to the temporary cue point and pause it. To
continue playback without returning to the temporary cue point, press and hold this button
and then press and hold the Play button, and then release both buttons.
Press and hold Shift and then press this button to return to the start of the track.
