9
RCD-M37 / RCD-M37DAB / D-E500 / D-M37
(2) Remove the screws.（ねじをはずす。）
(3) Disconnect the connector wire and remove the Front panel assy.（コネクタワイヤーをはずし、フロントパネルアッ
シーをはずす。）
Please refer to
"EXPLODED VIEW "
for the disassembly method of each P.W.B included in FRONT PANEL SUB ASSY.
FRONTPANELSUBASSY の各基板のはずしかたは "EXPLODEDVIEW" を参照してください。
Bottom view
CN53
Picture A
