Denon RCD-M38

15
(5) DisconnecttheFFCcable.
7. SPK UNIT
8. TRANS
9. GUIDE UNIT
FFC cable
Direction of photograph: B
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachPCBincludedinREARPANELSUBASSY.
Proceeding : TOP CABINET
REAR PANEL SUB ASSY
→
SPK UNIT
→
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofSPKUNIT.
Proceeding : TOP CABINET
REAR PANEL SUB ASSY
→
SPK UNIT
→
TRANS
→
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofTRANS.
Proceeding : TOP CABINET
REAR PANEL SUB ASSY
→
SPK UNIT
→
TRANS
→
GUIDE UNIT
→
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofGUIDEUNIT.
